| Model No. |
DM-06-V |
DM-06-F |
DM-13-HS-F |
DM-25HS-F |
DM-08-F |
| Drilling Capacity(steel( 60kg./sq.mm)/cast Iron) |
Ø3/ Ø4 |
Ø6 / Ø8 |
Ø10 / Ø12 |
Ø25 / Ø28 |
Ø8 / Ø10 |
| Tapping capacity(steel(60kg./sq.mm)/cast Iron) |
|
|
|
|
|
| Minimum size of Drilling - Tapping Operation |
Ø 0.2 |
Ø 0.5 |
Ø1.0 |
|
Ø 0.5 |
| Spindle |
| Spindle Nose Taper (normal) ( T ) |
ER-11(Collet) |
JT-1(Male) |
MT-1 (Female) |
MT-3 (Female) |
JT-2(Male) |
| Spindle Nose Taper (optional) ( T ) |
|
ER-11 (Collet) |
ER-16 (Collet) |
ER-25 (Female) |
MT-1 (Female) |
| Spindle Stroke ( S ) |
50 |
50 |
100 |
125 |
65 |
| Spindle Speeds |
Infinitely |
16 |
8 |
8 |
8 |
| Spindle Speed Range - ( I Speed ) |
710 ~ 25,000 |
250-355-560-900 |
630-1500-2250-4000 |
100-160-280-500 |
280-355-710-100 |
|
|
2240-3150-5600-8000 |
1250-3000-4500-8000 |
630-1000-1800-3150 |
2000-3150-5600-7500 |
| ( I Speed ) |
|
500-710-1120-1800 |
|
|
|
|
|
4500-6300-11200-16000 |
|
|
|
| Spindle Feed |
Manual |
Manual |
Manual |
Manual |
Manual |
| Spindle Axis to column Face ( throat ) ( A ) |
270 |
270 |
270 |
265 |
170 |
| Spindle Axis to column Axis |
295 |
295 |
295 |
295 |
190 |
| Spindle Nose to Base Plate (min./ max) ( C ) |
85 / 210 |
85 / 210 |
125 / 370 |
150 / 500 |
100 / 200 |
| Cloumn Diameter (O.D.) ( D ) |
48 |
48 |
48 |
73 |
40 |
| Clamping Area on Base Plate ( Q x R ) |
250 x 280 |
250 x 280 |
250 x 280 |
320 x 350 |
280 x 370 |
| T Slots on Base Plate (Size / Pitch / Nos.) |
10 / 50 / 3 |
10 / 50 / 3 |
10 / 50 / 3 |
14 / 160 / 2 |
10 / 100 / 2 |
| Motor( 3 Ph ) (KW / HP) |
0.37/ 0.5 |
0.25 / 0.33 - 0.37 / 0.5 |
0.60/ 0.80 - 0.8 / 1.1 |
1.1 / 1.5 |
1500 |
| Motor RPM |
3000 |
1500 / 3000 ( 2 Speed) |
1500 / 3000 ( 2 Speed) |
1500 |
1500 |
| Electric Supply |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
| Control Voltage |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
| Overall size of Base Plate ( W x L1 x H1 ) |
320 x 470 x125 |
320 x 470 x 125 |
320 x 470 x 125 |
320 x 470 x 125 |
280 x 370x 65 |
| Belt Type |
Flat |
Flat |
Flat |
V Belt |
Flat |
| Overall size of Machine ( W x L x H ) |
320 x 705 x 695 |
320 x 705 x 695 |
320 x 705 x 855 |
320 x 740 x 1150 |
280 x 580 x 620 |
| Machine Weight in Kgs. |
105 |
105 |
110 |
150 |
80 |
