| Model No. |
SM-25D-B/P |
SM-25TD-B/P |
SM-25TP- B/P |
SM-25DA-B / P |
SM-25TDE-B / P |
| Drilling Capacity ( steel (60kg./sq.mm) / cast Iron ) |
Ø25 / Ø 28 |
Ø25 / Ø 28 |
…….. |
Ø25 / Ø 28 |
Ø25 / Ø 28 |
| Tapping capacity ( steel (60kg./sq.mm) / cast Iron ) |
…….. |
M18 / M20 |
M18 / M20 |
…….. |
M18 / M20 |
| Minimum size of tapping Operation |
…….. |
M5 |
M5 |
…….. |
…….. |
| Spindle |
|
|
|
|
|
| Spindle Nose Taper ( T ) |
MT-3 (Female) |
MT-3 (Female) |
MT-3 (Female) |
MT-3 (Female) |
MT-3 (Female) |
| Spindle Stroke ( S ) |
150 |
150 |
150 |
125 |
125 |
| Spindle Speeds |
8 |
8 |
8 |
8 |
8 |
| Speed Range(std.) without Back Gear |
630-1000-1800-3150 |
400-710-1120-2000 |
400-710-1120-2000 |
630-1000-1800-3150 |
400-710-1120-2000 |
| Speed Range(std) with Back Gear |
100-160-280-500 |
64-100-180-280 |
64-100-180-280 |
100-160-280-500 |
64-100-180-280 |
| Spindle Feed |
Manual |
Manual |
Manual |
Auto + Manual |
Auto + Manual |
| No. of Autofeeds |
…….. |
…….. |
…….. |
2 |
2 |
| Rate of Autofeeds ( mm / rev ) |
…….. |
…….. |
…….. |
0.1 / 0.2 |
0.1 / 0.2 |
| Auto Feed Engagement (std) |
…….. |
…….. |
…….. |
Mechanical clutch |
…….. |
| Auto Feed Engagement (optional) |
…….. |
…….. |
…….. |
Electro-magnetic clutch |
Electro-magnetic clutch |
| Spindle Axis to column Face ( throat )( A ) |
250 |
250 |
250 |
230 |
230 |
| Spindle Nose to work Table (min./ max) - B / P ( C1 ) |
0 / 305 - 0 / 900 |
0 / 305 - 0 / 900 |
0 / 305 - 0 / 900 |
0 / 305 - 0 / 900 |
0 / 305 - 0 / 900 |
| Spindle Nose to Base Plate (min./ max) - B / P ( C2) |
200 / 600 - 450/1200 |
200 / 600 - 450/1200 |
200 / 600 - 450/1200 |
200 / 600 - 450/1200 |
200 / 600 - 450/1200 |
| Cloumn Diameter (O.D.) ( D ) |
80 |
80 |
80 |
80 |
80 |
| Clamping Area on work Table ( M x N ) |
235 x 235 |
235 x 235 |
235 x 235 |
235 x 235 |
235 x 235 |
| Clamping Area on Base Plate - B / P ( Q x R ) |
270 / 290 - 300 x 330 |
270 / 290 - 300 x 330 |
270 / 290 - 300 x 330 |
270 / 290 - 300 x 330 |
270 / 290 - 300 x 330 |
| T Slots on Work Table ( Size / Pitch / Nos.) |
12 / 125 / 2 |
12 / 125 / 2 |
12 / 125 / 2 |
12 / 125 / 2 |
12 / 125 / 2 |
| T slots on Base Plate (Size / Pitch / Nos.) |
14 / 160 / 2 |
14 / 160 / 2 |
14 / 160 / 2 |
14 / 160 / 2 |
14 / 160 / 2 |
| Motor 3Ph. TEFC (KW / HP) |
0.75 / 1.0 |
0.75 / 1.0 |
0.75 / 1.0 |
1.1 / 1.5 |
0.75 / 1.0 |
| Motor RPM |
1500 |
1000 (Rev.) |
1000 (Rev.) |
1500 |
1000 (Rev.) |
| Electric Supply |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
415V,3Ph,50Hz |
| Control Voltage |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
220V,1Ph,50Hz |
| Overall size of Base Plate - B ( W x L1x H1) |
350 x 520 x 110 |
350 x 520 x 110 |
350 x 520 x 110 |
350 x 520 x 110 |
350 x 520 x 110 |
| Overall size of Base Plate - P( W x L1x H1) |
380 x 560 x 125 |
380 x 560 x 125 |
380 x 560 x 125 |
380 x 560 x 125 |
380 x 560 x 125 |
| Belt Tupe |
V - Belt |
V - Belt |
V - Belt |
V - Belt |
V - Belt |
| Overall size of Machine - B( W x L x H ) |
350 x 700 x 1150 |
350 x 700 x 1150 |
350 x 700 x 1150 |
350 x 700 x 1150 |
350 x 700 x 1150 |
| Overall size of Machine - P( W x L x H ) |
380 x 710 x 1750 |
380 x 710 x 1750 |
380 x 710 x 1750 |
380 x 710 x 1750 |
380 x 710 x 1750 |
| Machine Weight in Kgs.- B / P |
140 / 150 |
140 / 150 |
140 / 150 |
150 / 160 |
150 / 160 |
